Diamond Grade Reflective Sheeting with Full-Cube Prismatic Construction and ASTM D4956 Type XI Compliance

ブランド名:	LU
型番:	LZT9800
MOQ:	1ロール
価格:	交渉可能
支払条件:	L/C、D/A、D/P、T/T、ウェスタンユニオン
供給能力:	10000ロール/月

詳細情報

製品説明

詳細情報

起源の場所:

中国

反射度:

ダイヤモンドグレード

パフォーマンスのクラス:

EN12899 クラス RA2/ASTM D4956 タイプ XI

反射的な建設:

フルキューブプリズマ

接着型タイプ:

感圧接着剤(PSA)

保証:

10年

表面材料:

アクリル

耐候性:

素晴らしい

サイズオプション:

さまざまなサイズのロールとシートをご用意しています

パッキング:

カートン

仕様:

48インチ*50ヤード；1.22*45.7m

パッケージの詳細:

1 ロール/カートン

供給の能力:

10000ロール/月

ハイライト:

10 years warranty Diamond Grade Reflective Sheeting

Full-cube prismatic Microprismatic Reflective Sheeting

ASTM D4956 Type XI Retroreflective Sheeting

製品説明

Diamond Grade Reflective Sheeting 9800 White

Premium diamond-grade microprismatic reflective material engineered for high-speed traffic environments and high-safety-level signage systems.

Technical Specifications

Item	Specification
Reflective Grade	Diamond Grade
Reflective Technology	Sealed microprismatic retroreflection
Typical Service Life	10 years (outdoor)
Thickness (without liner)	0.43 - 0.48 mm
Adhesive Type	Pressure-sensitive adhesive (PSA)
Substrate Compatibility	Aluminum and standard sign substrates
Operating Temperature	−30 °C to +65 °C
Application Temperature	≥ +10 °C
Weather Resistance	UV, moisture, and temperature resistant
Surface Properties	Dirt-resistant, easy to clean
Available Colors	White, Yellow, Red, Blue, Green (customizable)
Applicable Standards	ASTM D4956 Type XI

Utilizing advanced full-cube microprismatic retroreflection technology, the sheeting delivers exceptional brightness and superior visibility, even under nighttime conditions, rain, fog, and complex or low-light environments. Designed to meet the demanding requirements of permanent traffic control and safety applications, 9800 Diamond Grade Reflective Sheeting ensures clear and reliable recognition of road information at long viewing distances and wide entrance angles, significantly enhancing driver awareness and overall roadway safety.

Product Highlights

Diamond-Grade Microprismatic Construction
Incorporates a high-density microprismatic structure that provides significantly higher retroreflectivity than engineering-grade and high-intensity reflective sheetings.
Excellent Wide-Angle Performance
Maintains outstanding visibility at wide entrance and observation angles, ensuring clear recognition from long distances and improving early warning effectiveness for drivers.
Outstanding Outdoor Durability
Engineered for long-term outdoor use, offering excellent resistance to UV exposure, weathering, and temperature extremes without fading, cracking, or delamination.
High Installation Efficiency
Features a smooth, uniform surface that allows easy cutting, printing, and application, improving fabrication efficiency and reducing installation time.

Applications

Highway and expressway traffic signs
Urban road and arterial roadway signage

Diamond Grade Reflective Sheeting Manufacturer - LU

LU is a professional manufacturer specializing in diamond grade microprismatic reflective sheeting, dedicated to providing high-performance reflective solutions for traffic safety and industrial signage worldwide. With a strong focus on technology innovation, quality consistency, and long-term reliability, LU has established itself as a trusted supplier in the global reflective materials industry.
